Electronics Stamping Die

Electronics Stamping Die

6 single-stage dies: OP10–OP60
1.6 mm DP600
Operation-by-operation sample control
In-house tryout up to 800T
Send Inquiry
Description

Electronics Stamping Die – Six Single-Stage Tools From OP10 to OP60



This Electronics Stamping Die project uses six separate single-stage tools from OP10 through OP60. The part material is 1.6 mm DP600, so the process needs more than simple cutting and bending. Springback, hole movement and local profile changes have to be checked as the part develops through the six operations.

Using separate dies makes the process easier to read during tryout. Parts can be taken from OP10, OP20, OP30 and later stages and compared directly. If the geometry starts moving after one operation, the correction can stay with that tool instead of being pushed into OP50 or OP60.

The confirmed parameter data available for this page belongs to the OP60 tool. Parameters for OP10–OP50 are not assumed.

Electronics Stamping Die process samples from OP10 to OP60



Project Advantages



Six Independent Operations

OP10 through OP60 can be checked and adjusted separately. This makes it easier to keep a correction at the operation where the dimensional change actually begins.

Built Around 1.6 mm DP600

High-strength sheet requires attention to punch strength, bend recovery, local support and springback rather than treating the part like a thin terminal or shielding component.

Intermediate Samples Stay Useful

Parts from different OP stages can be compared for hole position, profile, bend condition and surface changes before the final OP60 sample is approved.

In-House Tryout up to 800T

Changdong's press capacity reaches 800T, with additional 400T, 260T, 160T and 45T presses available for different tooling programs.



Confirmed OP60 Tool Parameters



Item

Specification

Product Name

Electronics Stamping Die

Project Reference

BA41

Part No.

87319+87819-61M30

Version

Rev1.0

Part Material

DP600

Thickness

1.6 mm

Tool Stage

OP60

Project Route

OP10 / OP20 / OP30 / OP40 / OP50 / OP60



Read the Six Samples as One Process



The Finished Part Does Not Show Where a Problem Began

If the OP60 part shows a shifted hole, flange or surface, that does not automatically mean OP60 caused it. The change may have started several operations earlier.

Keeping the six process samples together gives the engineering team a simple way to see when the part starts to move away from the expected geometry. This is particularly useful with DP600 because springback from an earlier forming operation can affect features produced later.

One OP, One Clear Responsibility

The released process drawing defines what each die actually does. The page does not assign unconfirmed forming, trimming or piercing functions to OP10–OP60. During tryout, inspection follows the real operation sequence instead.



Electronics Stamping Die OP10 open single-stage tooling

OP10 – the first independent tool in the six-stage stamping route.



OP10: Give the Next Tool a Stable Starting Part



First Operation, First Check

Before later tools are adjusted, the OP10 part is checked for the features and geometry created by the first operation. An unstable starting part can make every following die look worse than it really is.

With a separate Electronics Stamping Die at OP10, the workpiece can be removed and inspected directly before it enters OP20.



Electronics Stamping Die OP20 open single-stage tooling

OP20 – second-stage single-operation tooling.



OP20: Check Location Before Changing Steel



The Part Should Sit Naturally

If the OP10 part does not locate correctly in OP20, forcing it into position can hide the real problem. Incoming geometry and locator contact are checked before working areas are modified.

High-Strength Material Makes This More Important

DP600 can retain residual stress after forming. A small amount of springback may change the way the part sits in the next die even when the earlier dimension looked acceptable immediately after stamping.



Electronics Stamping Die OP30 open single-stage tooling

OP30 – the third die in the OP10–OP60 sequence.



OP30: Compare the Part, Not Just the Die



Side-by-Side Samples Make Correction Faster

The OP20 and OP30 samples can be placed together to see what actually changed at this stage. Hole movement, local profile change, bend recovery or surface marking becomes easier to trace when the earlier part is still available.



Electronics Stamping Die OP40 open single-stage tooling

OP40 – fourth independent tool in the stamping route.



OP40: Do Not Move an Upstream Error Down the Line



Correction Belongs Where the Deviation Starts

If OP30 already shows a geometry problem, changing OP40 simply to make the part fit can create a second compensation. The better route is to identify what OP30 controls and correct it there whenever possible.

Check Assembly-Related Features Early

A dimension may pass on its own but still create interference in the final assembly. Hole relationship, formed surfaces and locating features can therefore be checked before the part reaches the final operation.



Electronics Stamping Die OP50 open single-stage tooling

OP50 – penultimate tool before the confirmed OP60 die.



OP50: Prepare the Part for Final Confirmation



OP60 Should Not Become a General Repair Station

Before the part enters the final die, the important upstream geometry should already be understood. This keeps OP60 focused on the result assigned to it rather than correcting several earlier conditions at once.

Surface Problems Are Easier to Trace Here

If a scratch or tool mark is already present on the OP50 sample, the final die can be ruled out immediately. This is a simple but useful reason to keep operation samples during tryout.



Electronics Stamping Die OP60 open final-stage tooling

OP60 – the final tool and the source of the confirmed parameter data shown above.



OP60: Final Sample and Assembly Check



Final Dimensions Are Read With the Process History

The OP60 sample is checked against the drawing, but the earlier samples remain useful. If a hole, flange or profile is outside requirement, the six-stage sample sequence helps show whether OP60 owns the issue or only inherited it.

Check More Than Numbers

Depending on the drawing, inspection can include hole position, surface / profile, bend angle, trimming condition, burr direction, scratches and visible tool marks.

The completed part can also be checked against its assembly condition so that a dimension that passes individually does not create interference later.

OK Means the Agreed Criteria Have Passed

Final OK samples are submitted only after the agreed dimensional and appearance items have passed inspection. The target for the finished sample is 100% against those agreed approval items.



Tooling Details That Matter With DP600



Punch Strength and Cutting Clearance

Higher-strength sheet increases the load on pierced and trimmed features. Punch section, support and cutting clearance need to suit the actual feature instead of being copied from softer-sheet tooling.

Springback Needs Its Own Correction

Changing a locator does not solve springback. Where the part opens or moves after forming, the forming condition or restrike strategy needs to be reviewed at the operation responsible for the shape.

Wear Components Should Be Accessible

Frequently serviced punches and inserts are easier to maintain when they can be replaced without dismantling unrelated parts of the Electronics Stamping Die.



Manufacturing Support for a Six-Tool Program



Six WEDM Machines

A six-die project creates many inserts, punches and precision profiles. Six WEDM machines allow several tool components to move through wire cutting without relying on one machine for the entire project.

CNC and High-Speed Drilling

CNC machining, including a 3-meter gantry machine, and high-speed drilling support die plates, structures and components required across several tools.

Presses up to 800T

Changdong's in-house press line includes 800T, 400T, 260T, three 160T presses and one 45T press. Relevant presses can be matched to the actual die and process requirement.



What We Need Before Quoting a Six-Stage Electronics Stamping Project



For a new Electronics Stamping Die program, please provide the dimensioned 2D drawing, matching 3D model, die technical standards and press specification.

The intended OP sequence is also useful when several single-stage dies are required. Add the material standard, thickness, critical assembly dimensions, surface requirements, expected annual volume, sample quantity and inspection format.

Where coating, specified component brands, spare inserts or checking fixtures are required, identify them at the quotation stage. This gives the engineering team enough information to plan the six tools as one project while keeping the responsibility of each OP clear.

Recommended Project Data

• 2D drawing

• 3D CAD / STEP model

• OP10-OP60 process plan

• DP600 material specification

• Die technical standards

• Press specification

• Critical assembly dimensions

• Surface requirements

• EAU

• Sample and inspection requirements



FAQ



Q: Why use six single-stage dies instead of putting several operations into one tool?

A: Separate tools make it easier to inspect intermediate parts, isolate dimensional changes and correct individual operations. This can be useful when part volume, press availability, high-strength material or the required forming route does not favor a progressive or transfer die.

Q: Why are the listed parameters identified as OP60 data?

A: The confirmed parameter sheet supplied for this page belongs to the OP60 tool. Dimensions, tonnage or other tooling data for OP10 through OP50 have not been provided, so they are not assumed or copied from OP60.
